1. Traction: 0 ~ 250kg.

2. Traction speed: 0 ~ 100m/min (constant tension follow-up).

3. Return speed: 0 ~ 200m/min two-stage speed regulation (touch screen input).

4. Larger clamping size: 240 wide by 150 high.

5. Large stroke: 41m (determined according to specific installation conditions).

6, orbit: 28 # H + 40 x 40 cold drawn steel square steel (flat butt, butt error < 0.15 ㎜).

7. Operation mode: manual and automatic (the extruder sends the extrusion signal forward and the extruder stops and returns).

8. Brake: use dc brake.

9. Traction frequency conversion motor power: 5.5kw.

10. Power of motor (with reducer box and brake) for opening and closing bracket and presser claw: 200w 2.

11. Main electrical components: PLC: mitsubishi; Frequency converter: yaskawa.

12. Power supply: 380V, 60Hz, 3-phase and 4-wire.

13. Air source: 0.4-0.7mpa, dosage: 3m /h.
